Heavy Duty Roll Turning Lathe With PLC

CG84125


CK84/CW84 series Roll Turning CNC Lathe are mainly used for turning not only the non-ferrous metals like various structure steels, casting steels and irons, but also the external/internal cylindrical / conical/ spherical surfaces, thread of non-metal materials like steel roller, and all kinds of the surface of curve rotary body.

National Serving Advisory Hotline: 0532-83205777/5888

Specifications Table of CK84 series Heavy Duty Roll Turning Lathe with PLC

Name/Type

Unit/Symbol

CK8465

CK8480

CK84100

CK84125

CK84160

CK84200









Basic Datas







Manuturing Brand



Mingtai

Mingtai

Mingtai

Mingtai

Mingtai

Mingtai

Guide Rail Type of Machine Bed



Three Guide Rails with Rectangle Type.

Three Guide Rails with Rectangle Type.

Three Guide Rails with Rectangle Type.

Three Guide Rails with Rectangle Type.

Three Guide Rails with Rectangle Type.

Three Guide Rails with Rectangle Type.

Machining Diameter of Work-piece K*2

mm

φ650mm

φ800mm

φ1000mm

φ1250mm

φ1600mm

φ2000mm

Guide Rail Width

mm

1000mm

1100mm

1400mm

1600mm

1800mm

2000mm

Chuck Diameter A

mm

φ630mm 4 jaws Independent Chuck

φ800mm 4 jaws Independent Chuck

φ1000 4 jaws Independent Chuck

φ1250mm 4 jaws Independent Chuck

φ1600mm 4 jaws Independent Chuck

φ2000mm 4 jaws Independent Chuck

Length of Chuck Jaw Seat (H)

mm

250mm heavy duty chuck jaw seat

250mm heavy duty chuck jaw seat

320mm heavy duty chuck jaw seat

320mm heavy duty chuck jaw seat

320mm heavy duty chuck jaw seat

320mm heavy duty chuck jaw seat

Max.Work-piece Length (B)

mm

4000mm

5000mm

8000mm

12000mm

15000mm

20000mm

Load Bearing Capacity

T

10T

18T

25T

32T

40T

50T

Spindle Diameter

mm

φ190mm

φ220mm

φ260mm

φ300mm

φ300mm

φ360mm

Gear Shifts of Spindle

gear shifts

3 gear shifts

3 gear shifts

3 gear shifts

3 gear shifts

3 gear shifts

6 gear shifts

Spindle Speeds

r/min

5~260r/min

2~165r/min

2~130r/min

2~130r/min

2~80r/min

0.5~80r/min

Tips Specifications of Spindle



Metric 80 1:7

Metric 80 1:7

Metric 100 1:7

Metric 120 1:7

Metric 120 1:7

Metric 160 1:7

X Axis Stroke (C)

mm

50-325mm

50-400mm

50-500mm

100-625mm

100-800mm

200-1000mm

Z Axis Stroke (D)

mm

1000-4000mm

1000-5000mm

2000-8000mm

2000-12000mm

3000-15000mm

3000-20000mm

Rapid Feed of X Axis

mm/min

2000mm/min

2000mm/min

2000mm/min

2500mm/min

2500mm/min

2500mm/min

Rapid Feed of Z Axis

mm/min

2500mm/min

2500mm/min

2500mm/min

2500mm/min

2500mm/min

3000mm/min

Cutting Tool Carriage Type



Square-type Cutting Tool Plate

Square-type Cutting Tool Plate

Square-type Cutting Tool Plate

Square-type Cutting Tool Plate

Square-type Cutting Tool Plate

Square-type Cutting Tool Plate

Pressure Cutter Size

mm

40*40mm

40*40mm

50*50mm

50*50mm

70*70mm

70*70mm

Tailstock Spindle Diameter

mm

φ240mm

φ290mm

φ290mm

φ320mm

φ320mm

φ410mm

Tailstock Sleeve Stroke(J)

mm

300mm

300mm

300mm

300mm

300mm

300mm

Tailstock Movement Method



Electrical Control

Electrical Control

Electrical Control

Electrical Control

Electrical Control

Electrical Control

Specifications of Tailstock Tips



Metric 80 1:7

Metric 80 1:7

Metric 100 1:7

Metric 120 1:7

Metric 120 1:7

Metric 160 1:7

Max.Cutting Force of Single Cutting Tool Holder

KN

40KN

50KN

50KN

80KN

100KN

150KN

Max.Cutting Force of Chuck

KN/m

13KN/m

22KN/m

33KN/m

40KN/m

90KN/m

233KN/m

Total Cutting Force

KN

45KN

60KN

70KN

110KN

160KN

210KN

CNC Control System



SIEMENS 828 D System

SIEMENS 828 D System

SIEMENS 828 D System

SIEMENS 828 D System

SIEMENS 828 D System

SIEMENS 828 D System









Motor Data







Main motor power (DC)

KW

22KW(According to the Work-piece with 3000 mm length)

37KW(According to the Work-piece with 3000 mm length)

45KW(According to the Work-piece with 3000 mm length)

55KW(According to the Work-piece with 5000 mm length)

75KW(According to the Work-piece with 7000 mm length)

128KW(According to the Work-piece with 8000 mm length)

Lubrication Motor Power

KW

0.37KW

0.37KW

0.55KW

0.55KW

0.55KW

0.55KW









Machine Accuracy Data







Cylindricity of Machine

mm

0.03/300mm

0.03/300mm

0.03/300mm

0.03/300mm

0.03/300mm

0.03/300mm

Machine Flatness

mm

0.03/300mm

0.03/300mm

0.03/300mm

0.03/300mm

0.03/300mm

0.03/300mm

Machine Roughness

Ra

Ra3.2

Ra3.2

Ra3.2

Ra3.2

Ra3.2

Ra3.2

Machine DimensionsL*W*H

mm

About 6000*2000*1400mm

About 7500*2200*1650mm

About 8100*2750*1950mm

About 10000*3100*2150mm

About 10500*3200*2400mm

About 12500*3600*2650mm

Machine Weight

T

About 20T(3m)

About 23T(3m)

About 26T(3m)

About 35T(5m)

About 46T(7m)

About 65T(8m)
